GENERAL DESCRIPTION

Model No P/N
TH-780C TH780C-N(M)

Mechanical Properties

Parameter Description
Antenna Type External Antenna
Touch Type Screw Type
Connector Type N 180˚(Male)
Antenna Dimensions 370mm ±10
Antenna Color Black
Operating Temperature Range -30°C~+80°C
Storage Temperature Range -30°C~+80°C

Electrical Properties

Parameter Description
Frequency Band 760~810 MHz
Nominal Impedance 50 ohm
Polarization Vertical
Electrical Wave Dipole
Return Loss Please See Data-1
V.S.W.R 2.5 : 1
Gain 0~3db
POWER 50W
